Technology Articles

2023-04 Power Laird Technologies

[Apr 11 2023] Laird Connectivity's Summit SOM 8M Plus System Module (SOM). It is a fully integrated hardware and software solution that combines NXP's multi-core processing, dual-band 2x2 Wi-Fi® 5 and Bluetooth 5.3 connectivity for multi-purpose advanced IoT applications such as robotics and machine learning. The Summit SOM 8M Plus module enables powerful heterogeneous multiprocessing based on a versatile, ene ...

2023-04 Semiconductors Nexperia

[Apr 11 2023] Nexperia's NCA9555 provides 16-bit universal Input/Output (GPIO) extensions for I²C bus /SMBus applications. It is designed for a wide voltage range of 1.65V to 5.5V and has interrupt and default pull-up resistance on the gpio. When additional IOs is needed, the Nexperia GPIO extender provides an elegant solution while keeping interconnections to a minimum, such as ACPI power switches, sensors, b ...

2023-04 Optoelectronics Hammond Manufacturing

[Apr 11 2023] Hammond Manufacturing's 1556 Series housing is formed in flame retardant ABS plastic and is ideal for printed circuit boards and a wide range of electronic devices. Available in black, white or light gray, the 1556 series features modern rounded edges and 14 sizes to choose from, including rectangular and square options. The 1556 series chassis can be installed in three different ways. Optional m ...

2023-04 Semiconductors Analog Devices

[Apr 10 2023] Analog Devices AD9177 16-bit DAC with wideband channel provides flexible reconfigurable universal platform design. The AD9177 is a highly integrated device with four 16-bit, 12-Gsps maximum sampling rate and RF digital-to-analog converter (DAC) cores supporting up to eight baseband channels. The device contains an 8-lane, 24.75Gbps JESD204C or 15.5Gbps JESD204B data receiver (JRx) port, on-chip c ...

2023-04 Power Texas Instruments

[Apr 10 2023] Texas Instruments LM5149/ LM5149-Q1 Synchronous step-down DC-DC controller is an 80V, ultra-low I(Q) synchronous step-down DC/DC controller suitable for high-current, single-output applications. The controller uses a peak current mode control architecture for easy loop compensation, fast transient response, and excellent load and line regulation. The LM5149/ LM5149-Q1 can be set to dual-phase mod ...

2023-04 Power Allegro MicroSystems, LLC

[Apr 10 2023] Allegro MicroSystems 3D magnetic potential sensor integrated circuits are robust, high-performance, precise 3D magnetic sensing solutions that combine the extensive expertise of planar and vertical Hall technologies. 3D magnetic potential sensor integrated circuits provide a wide range of contactless motion detection that works with virtually any moving magnet system, simplifying magnetic design ...

2023-04 Power Texas Instruments

[Apr 10 2023] Texas Instruments TPS7A53A-Q1 Ultra-low drop voltage (LDO) regulator is a low-noise (5.6µV(RMS), high-precision, ultra-low drop voltage linear regulator (LDO) capable of providing 3A sources with a drop voltage of only 130mV. The combination of low noise, high PSRR, and high output current capabilities makes the TPS7A53A-Q1 designed to power noise-sensitive components such as radar power and info ...

2023-04 Power ECS

[Apr 7 2023] ECS 'ECX-1637B2 series of Surface Mount (SMD) crystals are packaged in industry standard 2.0mm x 1.6mm x 0.45mm 4-pad ceramic. These electronic components offer a wide frequency range from 16 MHz to 50 MHz. They offer tight stability options of ±10ppm, tolerance of ±10ppm, and first year aging at low ±2ppm at +25°C±3°C, with the option of an extended operating temperature range. The standard ECX- ...

2023-04 Sensors Amphenol LTW

[Apr 7 2023] Amphenol LTW's overpressure release vent comes in a metal and plastic casing that balances the pressure inside and outside the sealed casing to prevent shortening the service life of the device and prevent potential damage to the internal components, performance degradation, or sudden heat/pressure rise of the battery module resulting in an explosion. IP68/IP69K waterproof protection and hydropho ...

2023-04 Power Renesas Electronics America

[Apr 7 2023] The RAA2S4252B is a member of the Renesas CMOS integrated circuit family for high-precision amplification and sensor-specific correction of differential bridge sensor signals. The RAA2S4252B features 900 maximum analog preamplification and analog Sensor offset correction (XSOC), which can be adjusted for almost all resistance Bridges. Conditioning calculations are performed with a 16-bit RISC mic ...

2023-04 Sensors TDK

[Apr 7 2023] TDK's B84143CxS250/S251 series are EPCOS 3-wire EMC filters for high current converter applications. Depending on the type, they are rated for 305 VAC/530 VAC and 440 VAC/760 VAC (50 Hz/60 Hz) and for 160 A to 2500 A currents. A particular performance characteristic is the very high attenuation figures they achieve in the range of 9 kHz to 150 kHz. To meet UL requirements in open-cabinet construc ...

2023-04 Connectors Bourns

[Apr 7 2023] Bourns' magnetic product line offers AAC-Q200 compliant SRP1050WA, SRP5030WA, SRP6030WA and SRP7050WA series of high current shielding power inductors designed to meet the requirements of high current density and high temperature in harsh vibration operating environments for a variety of electronic applications. They are manufactured with metal alloy powder cores with low DC resistance, high satu ...
